Cisco Meraki MS130-48P Cloud-Managed 48-Port PoE Gigabit Switch

MPN: MS130-48P-HW

$3,212.99reseller pricing · ex. tax

Free US shipping on orders $999+ · flat $9.90–$24.90 ground below

Meraki dashboard license — required to operate

$3,212.99 hardware · no license selected Total$3,212.99

Description

The Cisco Meraki MS130-48P is a cloud-managed Layer 2 access switch for branch and campus networks. 48 × 1 GbE access ports plus 4 × 1 GbE SFP uplinks — managed entirely from the Meraki dashboard, with no on-box CLI and no controllers to run.

48 × 1 GbE (RJ45) access ports plus 4 × 1 GbE SFP uplinks
104 Gbps switching capacity for line-rate forwarding
PoE — 802.3bt, up to 30 W/port, 740 W total budget, to power APs, IP phones, and cameras
Cloud-managed — VLANs, 802.1X, DHCP snooping, remote packet capture, and automatic firmware updates from the Meraki dashboard
1U rack-mount
Limited lifetime hardware warranty

A Meraki Enterprise or Advanced license is required to activate cloud management — choose your term below and we'll co-terminate it to your organization. Authorized Cisco Meraki reseller pricing; request a quote for volume.

Key specifications

Power

PoE 802.3bt, up to 30 W/port, 740 W total budget

Power supply Fixed internal

Power consumption 803 W max

Physical

Weight 12.13 lb (5.5 kg)

Mounting 1U rack-mount

Dimensions 1.73 × 17.32 × 13.4 in (4.4 × 44 × 34 cm)

Environment

Humidity 5%–95%

MTBF (25°C) 309,196 hours

Operating temperature 32–113°F (0–45°C)

Performance

Switching type Layer 2 access

Switching capacity 104 Gbps

Ports & Interfaces

Management 1 × dedicated management interface

Access ports 48 × 1 GbE (RJ45)

Uplink ports 4 × 1 GbE SFP

Licensing & Warranty

License required Enterprise or Advanced, 1/3/5/7/10-year (sold separately — select below)

Hardware warranty Limited lifetime

Management & Security

VLAN 802.1Q tagging

Tools Remote packet capture, automatic firmware updates

Security 802.1X authentication, DHCP snooping

Cloud management Cisco Meraki dashboard

Shipping

Shipping weight 18.38 lb

Shipping dimensions (L × W × H) 22.5 × 9 × 18 in

Full datasheet available on request. Specifications per Cisco; Zconnect is an authorized reseller and independent of Cisco Systems.

Meraki hardware needs a dashboard license

Meraki hardware won't come online without an active dashboard license. We match the right term to your hardware so nothing stops working at renewal — bundled into your quote above, or licensed separately.

View Licensing Options
